CP2022 3W Qi BPP接收Soc
作者: 时间:2023-09-22 17:34:22 点击次数:[890]

  Features:

  Integrated Wireless Power Supply Receiver

  Solution

  High Efficiency Full Synchronous Rectifier.

  WPC Qi V1.3 Compliant communication Control

  Single IC Required Between RX Coil and Output

  WPC Qi V1.3 FOD Function

  High Accurate Current Sense

  Easy to debug for certification by Resistance

  Current limit by external programming resistor

  Dynamic Rectifier VRECT

  Improve the Load Transient Response

  Optimize the dynamic efficiency for full load output

  Rectifier Overvoltage Clamp (VOVP=18V)

  Support 18-V Maximum Input

  Over Temperature, Over Voltage and Over

  Current Protection

  LED Output Indication

  Charging Complete and Fault Host Control

  VOUT with High Voltage Protection and Reverse current prevention

  QFN 3mm*3mm 16Pin Pack

  Specially optimized for small power and small or irregular coil applications


  Applications

  Wearable product

  Hand-held Device

  Portable Products(Audio, Media, Headsets)


CP2022 WPC1.3 规格书 SPEC V1.0 202212.jpg
